Basic Information
Supported CPU
Supports 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/ Athlon with Radeon Vega Graphics Desktop Processors for Socket AM4
Chipset: AMD B450 Chipset
Form Factor
M-ATX Form Factor
Audio
Realtek ALC892 Code:
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
Expansion Slots: PCI
- 1 x PCIe 3.0 x16 slot (PCI_E1)
- Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
- Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon
Graphics processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
- 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)1
- 2 x PCIe 2.0 x1 slots2
M.2 Socket
AMD B450 Chipset:
- 1 x M.2 slots (M2_2, Key M)1
- Supports PCIe 2.0 x4 2242/ 2260 /2280 storage devices
AMD CPU:
- 1x M.2 slot (M2_1, Key M)1
- Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen (AMD
Ryzen with Radeon Graphics) or PCIe 3.0 x2 (AMD Athlon with Radeon Vega Graphics)and SATA 6Gb/s 2242/
2260 /2280 storage devices
Memory
Type: DDR4
Slots
- 1 x PCIe 3.0 x16 slot (PCI_E1)
- Supports x16 speed with 1st, 2nd and 3rd Gen AMD Ryzen processors
- Supports x8 speed with Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics processors
- Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors
- 1 x PCIe 2.0 x16 slot (PCI_E4, supports x4 mode)
- 2 x PCIe 2.0 x1 slots
Supported Memory
- Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
- Supports 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
- Supports 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)
- Supports non-ECC UDIMM memory
- Supports ECC UDIMM memory (non-ECC mode)
Maximum Memory: support up to 64GB
Graphics
Only support when using AMD Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/ Athlon with Radeon Vega Graphics Processors
Max Shared Memory
Maximum shared memory of 2048 MB
Connector & Ports
HDMI
1 x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @30Hz, 2560x1600 @60Hz
Display Port (s)
1 x DisplayPort, support a maximum resolution of 4096x2304 @60Hz, 2560x1600 @60Hz, 3840x2160 @60Hz, 1920x1200 @60Hz
DVI-D (s)
Yes
USB (s)
AMD B450 Chipset:
- 1 x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panel
- 1 x USB 3.2 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel
- 2 x USB 3.2 Gen1 (SuperSpeed USB) ports available through the internal USB 3.2 Gen1 connector
- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors) AMD CPU
AMD Processor:
- 4 x USB 3.2 Gen1 (SuperSpeed USB) Type-A ports on the back panel
LAN Port (s)
1 x Realtek RTL8111H-CG Gigabit LAN controller
Supported Storage
AMD B450 Chipset:
- 4 x SATA 6Gb/s ports1
- 1 x M.2 slots (M2_2, Key M)1
- Supports PCIe 2.0 x4 2242/ 2260 /2280 storage devices
AMD CPU:
- 1x M.2 slot (M2_1, Key M)1
- Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD
Ryzen with Radeon Graphics) or PCIe 3.0 x2 (AMD Athlon with Radeon Vega Graphics)and SATA 6Gb/s 2242/
2260 /2280 storage devices
Audio
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
Internal I/O Ports
1 x 24-pin ATX 12V power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s connectors
2 x USB 2.0 connectors (support additional 4 USB 2.0 ports)
1 x USB 3.2 Gen1 connector (support additional 2 USB 3.2 Gen1 ports)
1 x 4-pin CPU fan connector
3 x 4-pin system fan connectors
2 x 5050 RGB LED strip 12V connectors
1 x Front panel audio connector
2 x System panel connectors
1 x Chassis Intrusion connector
1 x Clear CMOS jumper
1 x Serial Port connector
1 x Parallel Port connector
TPM (Trusted Platform Module )
1 x TPM module connector
