Basic Information
Supported CPU: Intel Socket 1151 for 9th / 8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Supports Intel® 14 nm CPU
Supports Intel® Turbo Boost Technology 2.0
Chipset: Intel B365
Form Factor: mATX Form Factor 9.6 inch x 8.6 inch ( 24.4 cm x 21.8 cm )
Audio
Realtek® ALC887 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Front Panel Jack-retasking
Audio Feature :
- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
Expansion Slots
PCI
1 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0/2.0 x1
M.2 Socket
2 x M.2 Socket 3 for M Key, Type 2242/2260/2280 devices
Memory
Slots: Dual Channel Memory Architecture
Supported Memory: 4 x DIMM, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Maximum Memory: 64GB
Graphics
Integrated Graphics Processor- Intel HD Graphics support
Multi-VGA output support : HDMI/DVI-D/D-Sub ports
- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 30 Hz
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
Max Shared Memory: 1024 MB
Connector & Ports
HDMI: 1 x HDMI
D-Sub (s): 1 x D-Sub
DVI-D (s): 1 x DVI-D
USB (s): 1 x USB 3.1 Gen 1 USB Type-CTM up to 5Gbps
4 x USB 3.1 Gen 1 Type-A
LAN Port (s): 1 x LAN (RJ45) port(s)
Audio: 1 x 8-channel Audio I/O
TPM (Trusted Platform Module ): 1 x TPM header
Warranty Information
Manufacturer Warranty: 1.5 Years
