MSI Z170A GAMING M5 LGA 1151 Intel Z170 HDMI SATA 6Gb/s USB 3.1 ATX Intel Motherboard (Used)

Basic Information

Supported CPU

AMD Ryzen™ processor

AMD 7th Generation A-series/ Athlon™ processor

Chipset: AMD X370

Form Factor: ATX Form Factor; 30.5cm x 23.0cm

Expansion Slots

PCI: 1 x PCI Express x16 slot, running at x16 (PCIEX16)

* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

* Actual support may vary by CPU.

(The PCIEX16 slot conforms to PCI Express 3.0 standard.)

1 x PCI Express x16 slot, running at x4 (PCIEX4)

3 x PCI Express x1 slots

* The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. The PCIEX4 slot operates at up to x2 mode when the PCIEX1_2/PCIEX1_3 slot is populated. The PCIEX4 slot operates at up to x4 mode when both of the PCIEX1_2 and PCIEX1_3 slots are empty.

(The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.)

M.2 Socket

1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4*/x2 SSD support)

Memory

Type: Dual channel DDR4 memory architecture

Slots: 4 x DIMM

Supported Memory: Support for DDR4 3200(O.C.) / 2933(O.C.) / 2667* / 2400 / 2133 MHz memory modules

* Support for higher than DDR4 2667 MHz may vary by CPU.

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules

Maximum Memory: 64 GB

Graphics

1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz

* Support for HDMI 1.4 version.

Max Shared Memory: 2 GB

Connector & Ports

HDMI

1 x HDMI port

USB (s)

ASMedia® USB 3.1 Gen 2 Controller:

2 x USB 3.1 Gen 2 Type-A ports (red) on the back panel

CPU:

4 x USB 3.1 Gen 1 ports on the back panel

Chipset:

6 x USB 3.1 Gen 1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

4 x USB 2.0/1.1 ports available through the internal USB headers

LAN Port (s)

Realtek® GbE LAN chip (10/100/1000 Mbit)

Supported Storage

1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4*/x2 SSD support)

* Actual support may vary by CPU.

8 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, and RAID 10

* Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

Audio

Realtek® ALC892 codec

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out

Internal I/O Ports

1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

2 x system fan headers

1 x system fan/water cooling pump header

1 x M.2 Socket 3 connector

8 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x S/PDIF Out header

2 x USB 3.1 Gen 1 headers

2 x USB 2.0/1.1 headers

1 x serial port header

1 x Trusted Platform Module (TPM) header

1 x Clear CMOS jumper

Manufacturing Warranty: No
